EV10DS130xG

Active

The EV10DS130xG is a 10-bit 3 GSps DAC with an integrated 4:1 or 2:1 multiplexer, allowing easy interface with standard LVDS FPGAs.

product image

EV10DS130xG

The Noise Power Ratio (NPR) performance , which is 10 Bit equivalent at 3 GSPS, over more than 900 MHz instantaneous bandwidth, and the 70 dB linearity (SFDR, IMD) over full 1st Nyquist zone at 3 GSPS (NRZ feature), makes this product well suited for in high-end applications such as arbitrary waveform generators and broadband DDS systems.

Download Datasheet

Features

  • Channels: 1
  • Package: LGA255 / CICGA255 / CCGA255
  • Rate: 3 GSPS
  • Resolution: 10-bit
  • Temperature Range: -55 to +125C

General

  • Status: Active

Qualification

  • Space Grade: No

TYPE

TYPE

EV10DS130A Errata Datasheet

Type: PDF

Download

EV10DS130xG Datasheet

Type: PDF

Download

Replacing Ev1xds130a With Ev1xds130b 2

Type: PDF

Download

Using Ev1xds130b Higher Than 2.1Gsps 3

Type: PDF

Download
