EV10AS940
This ADC enables direct conversion to Ka-Band, for every kind of systems, ground based or space based, for SATCOM payloads & SAR imaging.
The EV10AS940’s ultra wide bandwidth also enables multi-band operation thanks to the ability to digitize signals from L-Band to Ka-Band, combined with multiple DDC channels.
With a 2.5W power consumption at 12.8 GSPS, the EV10AS940 helps phased array trends toward digital beamforming by providing outstanding RF performance with very low power consumption.
Main benefits
• Enables in-orbit payload reconfiguration in multiple bands
• Ultra wide input bandwidth 33 GHz (-3 dB)
• Single ended analog and clock inputs to ease RF interfaces
• Low power: 2.5 W (at 12.8 GSps)
• Digital features: DDC with I/Q decimation (x2 to x1024), Multi-NCOs (x4), Fast Frequency Hopping (3 hop modes) and Beamforming
• Multi ADC synchronization
• Available in Space and Military versions
